Photoetch Capability

Engineering

  • 150 x 400 lathe
  • Two drill presses with x & y leadscrews
  • Bridgeport mill with series 2J2 head, fitted with Milvision readout in x, y, & z, accuracy
    +/- 0.02 mm
  • Tapmatic tapping attachments
  • Fluteless taps to M6
  • 3”, 4”, 6” mill vices
  • Slitting saws on 1” arbour
  • Repetition drilling to 700 cycles per hour
  • Thread gauges
  • Pneumatic clamping devices
  • 63ft & 13ft vibratory finishing machines
  • Bonderising and Al chromating equipment
  • Small parts processing equipment & drying to 130º
  • Scotchbrite scrubbing machine
  • 1200 mm guillotine
  • 13 ton variable stroke press
  • Urethane block pressing
  • Press brake and bender
  • Pem insertation equipment
  • Tool control system

Printing

  • Mesh from 120 to 12 T
  • Squeegee grinding equipment
  • Mesh tension measurement
  • Micropressor controlled oven
  • Direct and indirect stencils
  • Calibrated UV source 365μ
  • Registration via lay edge or dowel pins
  • Line resolution +/- 0.1.mm
  • Peelable & rigid mask
  • Insulator printing
  • Laminations
  • Saturn automatic printing machine



Drilling

  • Excellon unidrill
  • Bungard NC drill
  • Stack making equipment
  • Holes from 0.8mm
  • Solid carbide tooling
  • Stereo microscope
  • Depth control on drilling
  • Routing
  • Up to 24,000 holes per hour

Etching

  • Resco etching machine
  • Variable depth of etch
  • Pollution control equipment
  • Chromic acid micro etch
  • Alkali strippable resists
  • Multiple resists and etch cycles
  • Selective plating (Cu & Sn)
  • Electrowinning of Cu residues
  • Copper, brass, nickel silver, bronze & steels
  • Bright & matt surfaces
  • Post-etch plating & engineering










ISO 9001: 2015
